DESCRIPTION
– It is mainly used in 1.25G Ethernet.
– It can transmit up to 20km.
– It adopts 131Onm FP laser and1550nm PIN photo detector,
1550nm DFB laser and 1310nm PIN photo detector.
– Temperature range is Commerical: 0*C~70*C, Industrial: -40 to 85 *C
– It adopts Bi-Directional LC connector, supports DDM funtion.

FEATURE
– Supports 1.25Gbps/1.0625Gbps bit rates
– Bi-Directional LC connector
– Hot pluggable SFP footprint
– 1310nm FP laser and1550nm PIN photo detector
– 1550nm DFB laser and 1310nm PIN photo detector
– Applicable for 20Km SMF connection
– Low power consumption, < 0.8W
– Digital Diagnostic Monitor Interface
– Compliant with SFP MSA and SFF-8472
– Very low EMI and excellent ESD protection
– Operating case temperature:
– Commerical: 0 to 70 *C Industrial: -40 to 85 *C

APPLICATIONS
– Gigabit Ethernet
– Fiber Channel
– Switch to Switch interface
– Switched backplane applications
– Router/Server interface
– Other Optical Links
