FEATURE
– SFF-8431 compliant SFP+ form-factor connectors
– Hot-pluggable electrical interface
– Transmission data rate up to 10.3Gbps
– 850nm VCSEL laser
– PIN photo-detector
– Low power consumption < 1W per end
– Length up to 300m using OM3 MMF
– All-metal housing for superior EMI performance
– Operating case temperature range 0C to +70C

APPLICATIONS
– 10 Gigabit Ethernet
– 4G and 8G Fibre Channel Applications
– 1x InfiniBand QDR. DDR, SDR
– High-performance computing clusters
– Servers, switches, storage and host card adapters

OVERVIEW
Focomm SFP+ Active Optical Cables are direct-attach fiber assemblies with SFP+
connectors. They are suitable for very short distances and offer a cost-effective way to
connect within racks and across adjacent racks. Optone SFP+ Active Optical Cables’s
length is up to 300 meters on OM3 MMF.
