FEATURE
– Up to 2.5Gbps data-rate
– 850nm VCSEL laser and PIN photodetector
– 131 0nm FP laser and PIN photodetector for 2-40km transmission
– 1550nm DFB laser and APD photodetector for 80-120km transmission
– Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
– Digital Diagnostic Monitoring: Internal Calibration or External Calibration
– 300m transmission with 50/125um MMF
– 150m transmission with 62.5/125um MMF
– Compatible with RoHS
– +3.3V single power supply
– Operating case temperature range of 0ㆍC to +70*C (Standard)
or -40*C to +85*C (Industrial)
DESCRIPTION
– Class 1 laser product EN 60825-1 standards
– Compliant with SFP MSA and SFF-8472
– Compliant with SDH/SONET
– Duplex LC connector
– Hot pluggable
– 3.3V Single Power Supply
APPLICATIONS
– SDH STM-1, S-1.1,L-1.1, L-1.2
– SONET OC-3 IR1, LR1, LR2
– Router/Server interface
– Other optical transmission systems
