FEATURE
– Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3x auto-negotiation
– Extends distances ranging from 2km (multi-mode fiber) to
120km (single mode fiber)
– Supporting Hot Pluggable
– Optional 19″ System Chassis (OPT-MR16) holds up to
16 Media Converters
– Auto-negotiation of duplex(HDX/FDX) on RJ-45 port
– Auto MDI/MDI-X support on R.J-45 port
– Max. 2046 bytes packet at store-and-forward mode; Max.
9K bytes packet at cut-through mode
– Rate Limit function, 32Kbps
– Supporting Loopback, precisely locating the failure, convenient
for link test
– Supporting LFP, quickly locates the failure
– Supporting remote power off alarming
– Economical management function within bandwidth
– Supporting Remote management
– Easy installation with complete LED indicators for working situation
– With powerful network management function, supporting WEB
and SNMP
