DESCRIPTION
CAT6 Waterproof Shielded Connector can be completely sealed
and waterproof, andit worksnormal in wet and underwater environments, provide
waterproof, high-speed andstabletransmission to users. Working in underwater
wiring, which solves the Environmental requirements that ordinary products
can’t meet ; It conforms to the Gigabit Ethernet applicationsystem and suitable
for the connection of communication sockets between devicesandthework
area and provide up to 250MHz of avallable bandwidth.
FEATURES
Jack : Phosphor bronze, 15-50u inch gold plating over nickel incontact area
Insertion /Extraction : 750 mating cycles Min.( ISO/EC 11801. IEC 60603-7-5)
PCB : FR-4 ,UL94V-0
Storage Temperature : -40*C to 70*C
Operation Temperature : -10*C to 60*C
Housing : High-strength waterproof nyion material and sealing ringjoint,
pressure resistance, environmental protection, waterproof
International Protection : IP67
