PRODUCT DESCRIPTION
The equipment is 2*1000 Base-X, 4*10/100/1000 Base-T PoE Managed Industrial
Ethernet fast switch, through the fanless cooling circuit design, wide range working
environment temperature, high protection level and other technologies, provide high
/ low temperature, lightning protection and other outstanding industrial quality, and
integrated switching, safety and various rich protocols, simultaneously supported The
public Ethernet multi ring protection technology (ERPS) has greatly enhanced the
flexibility of the network and enhanced the reliability and security of the industrial
network. It can meet the deployment requirements of rail transit, safe city, intelligent
transportation, outdoor monitoring and other harsh environments.
FEATURE
Input Voltage : DC12~58V(Non-PoE), DC48~58V(PoE)
Operating Temperature : -40*C ~ +75C
Shell : IP40 protection, fanless design
Test Report : CCC, RoHS, FCC, CE
Anti-static : 8KV-15KV
MTBF : 100000 Hours
