OVERVIEW
SW-M-8G-2SFP is a Layer 2 plus managed switch equipped
with 8 Gigabit RJ45 ports, 2G SFP ports and a Console port. 8 R.J45
ports support 802. 3af/at (PoE+) standard and provide 150 W total PoE
power. The all-metal steel case and intemal power adapter are designed
for rack mounting. It supports unified management of the entire network
configuration and network management, which can simplify user operation
and improve the reliability of deployment.
FEATURE
– Provides 8 10/100/1000Mbps RJ45 ports, 2 10/100/1000Mbps SFP fiber ports and 1 console port.
– Supports IEEE802.3i, IEEE802.3u, JEEE802.3ab, IEEE802.3z, IEEE802.3x , IEEE802.3az, IEEE802.3af, IEEE802.3at.
– Supports MAC address auto-learning and auto-aging.
– 19 inches full metal iron shell and internal power adapter design, suitable for rack installation.
– Supports QoS, port mirroring, link aggregation protocol.
– Support DHCP Snooping, DHCP Relay, Option 82, DHCP client.
– CE, ROHS, FCC, UKCA , 802.1Q VLAN
