FEATURE
– Network based on GUI, easy operation w ith graded
management mode (common user, super user and
administrator).
– With centralized management and Top tree, several
chassis can be managed in the same interface at the
same time; with grouping management any converter
can be conveniently manipulated among many converters.
– Master/slave structure providing management module
(master, slave), maximum 4 chassis which can hold 128
fiber ports and RJ45 ports cascaded can be managed.
– Supporting protocols like CONSOLE, WEB, Telnet and SNMP
– Console management: Users can set up IP and users’ authonity, display/control local and remote media converters with WINDOWS.
– WEB management: Users can set up IP and users’ authority, display/control local and remote media converters with WEB on browser,
such as IE
