Outdoor Steel Cabinet Type C

Features

• Wall-mounted cabinet designed for outdoor use, ideal for CCTV systems, fiber optic distribution, industrial media converters, and Ethernet switches.
• Manufactured from 1.0 mm electro-galvanized steel, ensuring corrosion resistance and light weight. Includes 2.5 mm² green-yellow grounding wire.
• Finished with dark gray electrostatic powder coating for weather durability and professional aesthetics.
• Integrated rainproof top cover for water protection.
• Front door equipped with push-handle lock and flush cap for enhanced security.
• Both sides feature drilled ventilation fins to promote airflow and prevent moisture accumulation.
• 2.0 mm thick rear steel bracket for pole-mount installation.
• Roof rack supports mounting of blower fans (4") for efficient internal ventilation and extended equipment life.
• Optional sticker/label area available upon request.
• Cabinet top cover features rubber gasket sealing to prevent water ingress.
• Includes removable aluminum mounting plate (1.2 mm thick) for equipment installation for mounting internal components.
• Supports DIN rail-mounted components such as industrial media converters and Ethernet switches.
• Compatible with ground wire connections, splice tray, cable guide, and circuit breaker mounting.
• 2 Hole in Back Door
• 2 cable access holes at the rear panel.
• IP Rating: IP55 or IP66 (optional)
• Built-in fan x1
• Bracket thickness: 2.0 mm
