FEATURE
– 1x 10/100Mbps R.J45 port+ 1*10/100M male output port+1*(5.5*2.1mm)
DC output port
– Support IEEE 802.3at Ethemet power standard
– 10/100M data transmission
– Output voltage:12V(Default)
– Circuit protection to protect the connected device
– Top-quality design, stable and reliable
OVERVIEW
SW-POEST-FC-24, a cost-effective and high reliable remote PoE PD device based on standard IEEE802.3af, could split the power and
data transmitted through cable. It could provide power and data to device without PoE function when connecting with a PoE Switch or PSE Injector.
The output voltage is 12V, and equipped with PoE power supply device, it could flexibly expand the scale of Security Surveillance & Wireless Network
without the limitation of power line layout.
With transformer isolated design for circult input stage and output stage of the SW-POEST-FC-24 power, it strengthens anti-jamming capability
and protection for circuit. Also it effectively reduces PoE Switch Abnormal Power Supply Matters caused by common ground problem.Meeting the
standard of IEEE802.3af. Compatible with power supply methods of both End-span(1,2+ 3,6-) and Mid-span (4.5+ 7,8-). With the features of output power
at 24W, low ripple, more than 82% high efficiency, Port Isolation Protection: 1500V and Protection for short circult, over-current & over-temperature.
With 1 to 2 design, it could be working with device that support external PoE, and it also simplifies effectively the project wiring and maintenance.
