FEATURE
– Supply power to IP network surveillance cameras through Cat5 Etheret cable (PoE)
– 2x 10/100 Mbps RJ45 ports, 1x high power PoE port, special for high-speed
dome cameras
– Support network port, lightning-proof power input port (the secondary lightning
– Support LT PoE++ high power PoE standard, compatible with IEEE802.3af /
IEEE802.3at standard.
– Single PoE port output power is 60W max.
– Input voltage: 56V; Output: DC12V/24V
– No fans, natural cooling, small and exquisite, no noise design, sultable for desktop
or wall
OVERVIEW
This single port 10/100M 60W PoE splitter is Focomm independent research and development for high power PoE splitter, it supports LT
PoE++ high power PoE standard, and can be backward compatible with IEEE 802.3af/IEEE802.3at PoE standard. The maximum output power is 60W,
the total power can be up to 75W. This high power PoE splitter can provide the maximum output power must be matched with high power PoE switch or
power injector, the output power will be less than 25.5W if matched with IEEE802.3af/IEEE802.3at standard PoE switch.
PoE spltter can provide a simple and economical solution for high performance Ethernet PoE power supply and data comn munication. Easy to
use and install, superior performance and cost-effective, which is an ideal choice for customer to improve the projects’ quality. It’s an efficient engineering
solution to meet the requirement of the reliability system and simplified installation for remote places without power supply or unable to use Ethernet cable
to supply power.
protection)
