DESCRIPTION
This series keystone jack work together with high speed cables,
cords and panels to provide performance beyond proposed
Category 6 standards, a new feature of this series Jack is a
universal colored wiring label that eliminates the need for
separate codes for T568A/B wiring scheme.
FEATURE
– Available in Cat 6, T568A/B wiring schemes, meet or exceed TIA/EIA
– Cat6 requirements
– Housing : high temperature thermoplastic
– Compact jack design,8 positions and 8 conductors
– Contact : phosphor bronze , phosphor bronze with 6 to 50p” gold plate
– Accept 22-26 AWG solid with a insulation diameter of 0.4-0.6 mm
– Easy to be terminated, extremely low attenuation loss and high return loss
– High reliability and superior performance
– Available in different colors
