FEATURE
ㆍSurface finish: degreasing, pickling, phosphoric, p powder coating.
The thickness of powder coating is 80um – 100um, complying with ROHS.
ㆍ By adopting heavy duty nylon silent pulley and aluminum alloy hanger rall,
the sliding door can be opened and closed easily. And the locks on the
door are convenient for people managing the cold pool channel.
* The material of sliding door is double -deck cold -rolled sheet metal which
make sure a good intensity of the door; And the middle of the door is made
up of clear tempering glass which allow the outside people checking the
situation of inside channel.
ㆍ The support beam on the top of cold pool channel is used for placing
tempering glass. The thickness of the support beam is 1.5mm.
APPLICATION
Mainly applied in Finance, Securities and Data Centre, etc.
MATERIAL
Galvanized Cold – rolled steel sheet. Thickness for hanger rail
2.0 mm,support beam 1.5mm, sliding door 1.2 mm. Heavy
duty nylon silent pulley.
