ELECTRICAL CHARACTERISTICS
1.Rating Temp:75 C
2.D-C Resistance:7.5 Ohm/1000M at 20 C
3.Dielectric Srength:AC 0.75kv/m
4.Spark test:2KV/0.15sec
5.Nominal impedance(OHMS):100+15%
6.Pair-1P-Ground Capacitance Unbalance Max 350pf/100m
7.Propagation Delay Skew:45nS/100M
COLOUR
1.BLUE WHITE/BLUE
2.0RANGE”WHITE/ORANGE
3.GREEN *WHITE/GREEN
4.BROWN*WHITE/BROWN
PHYSICAL PROPERTIES
1.Tensile Strengh test are before aging:
Sheath:> 1.41kg/mm
Insulation>1.68kg/mm
2.Tensile Strength test are after aging:
Sheath > 85% Tensile Strength test are
before aging Insulation > 75%,Tensile
Strenght test are before aging
3.Elongation after aging: Sheath 50%
Elongation before aging Insulation >75%
Elongation before aging
