OVERVIEW
Outdoor wall type fiber optic distribution frame is
mainly used for connecting the outdoor optical cables, optical
patch cords and optical pigtails. It can be wall mounted or
pole mounted, and facilitates the test and refit of thelines.
FEATURES
– With plastic plates can manage both single fiber and ribbon
& bundle fiber cables
– FC, LC, SC, ST output interfaces optional
– Large working space to integrate the pigtail, cables and
adapters
– Made of cold roll steel, electrostatic powder spraying
– Special design ensures the excess fiber cords and pigtails
in good order
– Inner components as follows:
– Fiber Optic Splice Tray: storing fiber connectors (together
with the protective components) and the spare fibers
– Fixing Device: used for fixing the fiber protective tubes,
the fiber reinforced cores and the distribution pigtails
– The brim of the box is sealed
APPLICATION:
– Telecommunications subscriber loop
– Fiber to the home (FTTH)
– LAN/WAN
– CATV
